Edison JM70100-1CR Modular Fuse Block, 700 V, 100 A, 1 Pole

Short Description

These new Bussmann series fuse blocks contain multiple features that increase versatility, reduce labor and enhance safety for any panel or electrical system design.

Edison Modular Fuse Block, Series: JM Series, 700 V, 100 A, 1 Pole, Class: J, Panel Mount
MFG #: JM70100-1CR

EECO #: BUJM701001CR

Brand: Edison
UPC #: 051712514729
Attributes
Features
Documents
Product Information
Attributes
Class
J
UNSPSC
39121629
Material
Thermoplastic
Wire Size
14 to 2 AWG Cu, 8 to 2 AWG Al
Application
Electrical Assemblies, Panels and EOEMs Applications
Mounting Type
Panel
Voltage Rating
700
Connection Type
Box Lug
Temperature Rating
-40 to 120
Type
Modular
Series
JM Series
Dimensions
3.69 in L x 2.57 in W x 1.53 in H
Amperage Rating
100
Features
  • To reduce inventory, assembly time and labor, modular 1-pole blocks snap-together for tool-less assembly of multiple poles at point of use
  • DIN-rail and panel mount versatility allows one product to be used for multiple applications, lowering inventory cost
  • Save panel space with the smallest width dimension on the market
Bussmann_JM70100_1CR_Specification_Sheet
