Bussmann Limitron™ JKS-2 Fast Acting Current Limiting Low Voltage Fuse, 2 A, 600 VAC, 200 kA Interrupt, J Class, Cartridge Body
Share Share Print Print
Eaton

Bussmann Limitron™ JKS-2 Fast Acting Current Limiting Low Voltage Fuse, 2 A, 600 VAC, 200 kA Interrupt, J Class, Cartridge Body

Short Description

Bussmann's UL Class J fuse products extend both our Low-Peak family of products with our LPJ_SP and LPJ_SPI dual-element, time-delay fuses as well as our Limitron line offering fast-acting JKS fuses. The LPJ fuses provide industry leading 300,000 amp interrupting rating at 600Vac RMS Sym and 100kA Vdc while delivering a minimum of 10 seconds of 500% rated current ride-through performance which is ideal for sizing of high inrush loads. The LPJ products are available with optional permanent replace fuse indication. These UL Class J products in sizes 1 to 600 amps provide exceptional performance at 600 Vac and 300 Vdc (see spec sheets for specific details) in a compact size rejecting footprint

Bussmann Limitron™ Fuse, Fast Acting Current Limiting Low Voltage, Series: JKS, Indicating/Non-Indicating: Non-Indicating, 2 A, 600 VAC, 200 kA Interrupt, Class: J, Ferrule Terminal, Holder Mount, Cartridge Body Type, Single Element, 0.81 in Dia x 2.25 in L Body Size
MFG #: JKS-2

EECO #: BUJKS2

Brand: Bussmann
UPC #: 051712630023
Attributes
Features
Documents
Product Information
Attributes
Class
J
UNSPSC
39121626
Material
Melamine
Application
Power Panelboard and Machinery Disconnects, Safety and Security Systems
Mounting Type
Holder
Terminal Type
Ferrule
Voltage Rating
600
Type
Fast Acting Current Limiting Low Voltage
Series
JKS
Amperage Rating
2
Features
  • Current limitation for non-inductive circuits provides class J current limiting response to maximum ground fault and short circuit conditions
  • 200 kA interrupt rating provides high ratings at all circuit locations
  • Economical solutions for high fault circuits
  • Fast acting fuse helps prevent equipment damage caused by short circuit events
Bussmann_JKS_2_Specification_Sheet
Bussmann_JKS_450_User_Manual_CA
