Bussmann Limitron™ T-Tron® JJS-600 Fast Acting Current Limiting Low Voltage Fuse, 600 A, 600 VAC, 200 kA Interrupt, T Class, Cartridge Body

Short Description

Bussmann's Class T current-limiting, fast-acting fuses. Provides 10X better current limitation to help prevent equipment damage caused by short-circuit events. 200 kA Interrupting rating complies with NEC Section 110.9 for today s large capacity systems. Small, space-saving fuses provide a high degree of current limitation on short-circuits for excellent component protection.

Bussmann Limitron™ T-Tron® Fuse, Fast Acting Current Limiting Low Voltage, Series: JJS, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 600 A, 600 VAC, 200 kA Interrupt, Class: T, Bolted Blade Terminal, Holder Mount, Cartridge Body, Single Element, Melamine, 1.25 in Dia x 3.98 in L Body Size
MFG #: JJS-600

EECO #: BUJJS600

Brand: Bussmann
UPC #: 051712628051
Attributes
Features
Documents
Product Information
Attributes
Class
T
UNSPSC
39121626
Material
Melamine
Application
Large Apartment Complexes, Multi-Family Meter Stacks, VFD Line Protection, Safety and Security Systems
Mounting Type
Holder
Terminal Type
Bolted Blade
Voltage Rating
600
Type
Fast Acting Current Limiting Low Voltage
Series
JJS
Amperage Rating
600
Features
  • Series combination ratings with branch circuit breakers allows broad range of coverage, independent of breaker manufacturer
  • Current limitation for non-inductive circuits provides class T current limiting response to maximum ground fault and short circuit conditions
  • 200 kA interrupt rating provides high ratings at all circuit locations
  • Small footprint allows more efficient use of available space
