Bussmann Limitron™ Tron® JJS-40 Current Limiting Very Fast Acting Fuse, 40 A, 600 V, 200 kAIC Interrupt, T Class, Cylindrical Body

Short Description

Bussmann's Class T current-limiting, fast-acting fuses. Provides 10X better current limitation to help prevent equipment damage caused by short-circuit events. 200 kA Interrupting rating complies with NEC Section 110.9 for today s large capacity systems. Small, space-saving fuses provide a high degree of current limitation on short-circuits for excellent component protection.

Bussmann Limitron™ Tron® Fuse, Current Limiting Very Fast Acting, Series: JJS, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 40 A, 600 V, 200 kAIC Interrupt, Class: T, Ferrule End Terminal, Holder Mount, Cylindrical Body Type, Single Element, Melamine, 1 in Dia x 1.56 in L Body Size
MFG #: JJS-40

EECO #: BUJJS40

Brand: Bussmann
UPC #: 051712628402
Attributes
Features
Documents
Product Information
Attributes
Class
T
UNSPSC
39121626
Material
Melamine
Application
Industrial Facilities and Factories, Safety and Security Systems, Large Apartment Complexes, Multi-Family Meter Stacks and VFD Line Protection Applications
Mounting Type
Holder
Terminal Type
Ferrule End
Voltage Rating
600
Type
Current Limiting Very Fast Acting
Series
JJS
Amperage Rating
40
Features
  • Small footprint allows more efficient use of available space
  • Series combination ratings with branch circuit breakers allows broad range of coverage, independent of breaker manufacturer
  • Current limitation for non-inductive circuits provides class T current limiting response to maximum ground fault and short circuit conditions
  • 200 kA interrupt rating complies with NEC section 110.9 for today's large capacity systems
  • Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
  • Fast acting fuse helps prevent equipment damage caused by short circuit events
  • Small, space saving fuses provide a high degree of current limitation on short circuits for excellent component protection
