Bussmann Limitron™ JJS-125 Fast Acting Current Limiting Fuse, 125 A, 600 VAC, 200 kA Interrupt, T Class, Cartridge Body

Short Description

Bussmann's Class T current-limiting, fast-acting fuses. Provides 10X better current limitation to help prevent equipment damage caused by short-circuit events. 200 kA Interrupting rating complies with NEC Section 110.9 for today s large capacity systems. Small, space-saving fuses provide a high degree of current limitation on short-circuits for excellent component protection.

Bussmann Limitron™ Fuse, Fast Acting Current Limiting, Series: JJS, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 125 A, 600 VAC, 200 kA Interrupt, Class: T, Bolted Blade Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine, 0.88 in Dia x 3.25 in L Body Size
MFG #: JJS-125

EECO #: BUJJS125

Brand: Bussmann
UPC #: 051712628129
Attributes
Features
Documents
Product Information
Attributes
Class
T
UNSPSC
39121626
Material
Melamine
Application
Large Apartment Complexes, Multi-Family Meter Stacks, VFD Line Protection, Safety and Security Systems
Mounting Type
Holder
Terminal Type
Bolted Blade
Voltage Rating
600
Type
Fast Acting Current Limiting
Series
JJS
Amperage Rating
125
Features
  • Small footprint allows more efficient use of available space
  • Series combination ratings with branch circuit breakers allows broad range of coverage, independent of breaker manufacturer
  • Current limitation for non-inductive circuits provides class T current limiting response to maximum ground fault and short circuit conditions
  • 200 kA interrupt rating complies with NEC Section 110.9 for today's large capacity systems
  • Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
  • Fast acting fuse helps prevent equipment damage caused by short circuit events
  • Small, space saving fuses provide a high deg of current limitation on short circuits for excellent component protection
