Eaton

Bussmann HM60030-3CR Modular Fuse Block, 600 V, 0 to 30 A, 3 Poles

Short Description

600 V, 1/2 to 30 A, 3-Pole, Thermoplastic Base, Class H, Modular Ferrule Fuse Block

Bussmann Fuse Block, Modular, Series: HM Series, 600 V, 0 to 30 A, 3 Pole, Class: H/K

MFG #: HM60030-3CR

EECO #: BUHM600303CR

Brand: Bussmann
UPC #: 051712511476
Attributes
Features
Documents
Product Information
Attributes
Class
H/K
UNSPSC
39121629
Approval
UL, CSA, CE
Material
Thermoplastic Base
Wire Size
2 to 14 AWG Copper, 2 to 8 AWG Aluminum
Application
Electrical Assemblies, Panels and EOEMs Applications
Terminal Type
Box Lug
Voltage Rating
600
Number Of Poles
3
Fuse Voltage Rating
600 Volt
Type
Modular
Series
HM Series
Fuse Type
Class H
Amperage Rating
0 to 30
Fuse Current Rating
1/2 to 30 Amp
Suitable For Use With
Midget Fuse
Features
  • To Reduce Inventory, Assembly Time and Labor, Modular Single-Pole Blocks Snap Together for Tool-Less Assembly of Multiple Poles at Point of Use
  • DIN Rail and Panel Mount Versatility Allows One Product to be Used for Multiple Applications with Lower Inventory Cost
  • Save Panel Space with the Smallest Width Dimension on the Market
  • Standard Clip Reinforcing Springs Improve Temperature Rise Performance While Maintaining Reliable Surface Contact Between the Fuse Ferrule and Clip Over the Block's Service Life
COBUSS_HM60030_3CR_CAD
COBUSSE02767_1_5_8
COBUSSE03317_8_19
Qty Unit price
Ea
1 $49.10

Slqt
1 $196.40

Stpk
1 $196.40

Unit
1 $196.40
