Edison HM25030-2QR Modular Ferrule Fuse Block, 250 V, 30 A, 18 to 10 AWG Cu Wire, 2 Poles

Name: Edison HM25030-2QR Modular Ferrule Fuse Block, 250 V, 30 A, 18 to 10 AWG Cu Wire, 2 Poles
Brand: Eaton
SKU: BUHM250302QR
Availability: InStock

Short Description

HM Class H(K), JM Class J and RM Class R modular ferrule fuse blocks for fuses up to 60 A. The new Bussmann® series fuse blocks contain multiple features that increase versatility, reduce labor and enhance safety for any panel or electrical system design.

Edison Modular Ferrule Fuse Block, Series: HM Series, 250 V, 30 A, 2 Pole, Class: H, Quick-Connect, 18 to 10 AWG Cu Wire, Panel Mount, -40 to 120 deg C, Thermoplastic, 3.2 in L x 2 in W x 2 in H

MFG #: HM25030-2QR

EECO #: BUHM250302QR BUHM250302QR

Brand: Edison

UPC #: 051712511193

Attributes

Features

Documents

Product Information

Attributes

Class

UNSPSC

39121629

Material

Thermoplastic

Wire Size

18 to 10 AWG Cu

Application

Electrical Assemblies, Panels and EOEMs Applications

Mounting Type

Panel

Voltage Rating

250

Connection Type

Quick-Connect

Temperature Rating

-40 to 120

Type

Modular

Series

HM Series

Includes

Screw

Dimensions

3.2 in L x 2 in W x 2 in H

Amperage Rating

Suitable For Use With

NON, NOS Series Fuse

Features

To reduce inventory, assembly time and labor, modular 1-pole blocks snap-together for tool-less assembly of multiple poles at point of use
DIN-rail and panel mount versatility allows one product to be used for multiple applications, lowering inventory cost
Save panel space with the smallest width dimension on the market

HM25030_2QR_Specification_Sheet
