EATON Edison ECSR4 Current Limiting Time Delay Fuse, 4 A, 600 VAC, 200 kA Interrupt, Class: RK5, Cartridge Body

Short Description

Edison's UL Class RK5 dual-element, time-delay fuses provide economical solutions to overcurrent protectioni. Available in both 250Vac and 600Vac, with 200kA RMS Sym interrupting ratings and sizes ranging from 0 to 600 amp.

EATON Edison Time Delay Fuse, Current Limiting, Non-Indicating, 4 A, 600 VAC, 200 kA Interrupt, Class: RK5, 10 s at 500% Response, Ferrule End x Ferrule End Terminal, Cartridge Body, Dual Element, 0.81 in Dia x 5 in L Body
MFG #: ECSR4

EECO #: BUECSR4

Brand: Eaton
UPC #: 782634508205
Attributes
Features
Documents
Product Information
Attributes
Class
RK5
UNSPSC
39121606
Material
Fiberglass
Application
AC Power Distribution System Mains, Feeders and Branch Circuits, Protection of Motor and Motor Branch Circuits, Transformers and Other Inductive Loads, Lighting, Heating and Other Non-Inductive Loads Applications
Mounting Type
Holder
Response Time
10 s at 500%
Terminal Type
Ferrule End x Ferrule End
Voltage Rating
600
Type
Current Limiting
Series
ECSR
Amperage Rating
4
Features
  • Superior overload and cycling capabilities
