Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class
Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class
Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class
Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class
Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class
Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class
Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class
Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class
Share Share Print Print
Eaton

Bussmann Edison ECNR175 Current Limiting Time Delay Fuse, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, RK5 Class

Short Description

Edison's UL Class RK5 dual-element, time-delay fuses provide economical solutions to overcurrent protectioni. Available in both 250Vac and 600Vac, with 200kA RMS Sym interrupting ratings and sizes ranging from 0 to 600 amp.

Bussmann Edison Fuse, Current Limiting Time Delay, Series: ECNR, Indicating/Non-Indicating: Non-Indicating, 175 A, 250 VAC/125 VDC, 200 kAIC Interrupt, Class: RK5, 10 s at 500% Response, Blade End Terminal, Dual Element, Fiberglass, 1.56 in Dia x 7.13 in
MFG #: ECNR175

EECO #: BUECNR175

Brand: Edison
UPC #: 782634507475
Attributes
Features
Documents
Product Information
Attributes
Class
RK5
UNSPSC
39121606
Material
Fiberglass
Application
Industrial Facilities and Factories, Safety and Security Systems, AC Power Distribution System Mains, Feeders and Branch Circuits, Protection Of Motor and Motor Branch Circuits, Transformers and Other Inductive Loads, Lighting, Heating and Other Non-induc
Mounting Type
Clip
Response Time
10 s at 500%
Terminal Type
Blade End
Voltage Rating
250 VAC/125 VDC
Type
Current Limiting Time Delay
Series
ECNR
Amperage Rating
175
Features
  • Superior overload and cycling capabilities
ECNR175_Specification_Sheet
PONC15_Catalog
Bussmann_ECNR175_Specification_Sheet_CA
