Eaton

Bussmann DFJ-175 Current Limiting High Speed Fuse, 175 A, 600 VAC/450 VDC, 100/200 kA Interrupt, J Class, Cartridge Body

Short Description

High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.

Bussmann High Speed Fuse, Current Limiting, Series: DFJ, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 175 A, 600 VAC/450 VDC, 100/200 kA Interrupt, Class: J, Blade Terminal, Stud Mount, Cartridge Body Type, Silver Element, Melamine, 1.63 in Dia x 5.75 in L Body Size
MFG #: DFJ-175

EECO #: BUDFJ175

Brand: Bussmann
Attributes
Features
Documents
Product Information
Attributes
Class
J
UNSPSC
39121626
Material
Melamine
Application
Protection of AC and DC Drives and Power Semiconductor Devices, Safety and Security Systems
Mounting Type
Stud
Terminal Type
Blade
Voltage Rating
600 VAC/450 VDC
Type
Current Limiting
Series
DFJ
Amperage Rating
175
Features
  • Easily co-ordinated with existing and new variable speed drives and electric controllers
  • Standard class J dimensions allowing the use of readily available fuse blocks, holders and switches
  • Allows the lowest let-thru energy of any branch circuit over current protective device
  • Silver fuse element
  • They provide maximum protection for AC and DC drives and controllers and meet NEC® branch circuit protection requirements
  • The DFJ drive fuse has the lowest I2t of any branch circuit fuse to protect power semiconductor devices that utilize diodes, GTOs, SCRs and SSRs
