Bussmann DFJ-12 Current Limiting High Speed Fuse, 102 A, 600 VAC/450 VDC, 100/200 kA Interrupt, J Class, Cartridge Body

Short Description

The Bussmann series DFJ drive fuse is a high speed, current limiting fuse that provides maximum protection for AC and DC drives and controllers and meet NEC branch circuit protection requirements. The drive fuse has the lowest I2t of any branch circuit fuse to protect power semiconductor devices that utilize diodes, GTOs, SCRs and SSRs.

Bussmann High Speed Fuse, Current Limiting, Series: DFJ, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 102 A, 600 VAC/450 VDC, 100/200 kA Interrupt, Class: J, Ferrule Terminal, Stud Mount, Cartridge Body Type, Silver Element, Melamine, 0.81 in Dia x 2.25 in L Body Size

MFG #: DFJ-12

EECO #: BUDFJ12

Brand: Bussmann
UPC #: 051712653275
Attributes
Features
Documents
Product Information
Attributes
Class
J
UNSPSC
39121626
Approval
UL, CSA C22.2, CE
Material
Melamine
Application
Protection of AC and DC Drives and Power Semiconductor Devices, Safety and Security Systems
Mounting Type
Stud
Terminal Type
Ferrule
Current Rating
12 Amp
Voltage Rating
600 VAC/450 VDC
Characteristics
High Speed, Non-Indicating, Current Limiting
Interrupting Rating
200 Kiloamp (Symmetrical), 100 Kiloamp (DC)
Type
Current Limiting
Series
DFJ
Diameter
0.81 Inch
Amperage Rating
102
Features
  • Easily co-ordinated with existing and new variable speed drives and electric controllers
  • Standard class J dimensions allowing the use of readily available fuse blocks, holders and switches
  • Allows the lowest let-thru energy of any branch circuit over current protective device
  • Silver fuse element
  • They provide maximum protection for AC and DC drives and controllers and meet NEC® branch circuit protection requirements
  • The DFJ drive fuse has the lowest I2t of any branch circuit fuse to protect power semiconductor devices that utilize diodes, GTOs, SCRs and SSRs
