Bussmann Limitron™ CC-Tron® BK/FNQ-R-1/4 Advanced Protection Current Limiting High Inrush Low Voltage Time Delay Fuse, 250 mA, 600 V, 200 kAIC Interrupt, CC Class, Cartridge Body

Short Description

Bussmann's Class CC fuses set the standard in Class CC fuse performance in the industry. Recognized for their superior performance, Bussmann has the right product for your circuit and equipment protection needs. These branch circuit rated, 600v, 200,000a IR fuses offer exceptional protection in the smallest package of any UL class of fuses. Choose from the ultimate protection provided by our Low Peak LP-CC fuses, the time delay of our FNQ-R's for your control transformer and similar control applications or the fast acting protection of our KTK-R Limitron fuses for specialized circuits such as lighting protection

Bussmann Limitron™ CC-Tron® Fuse, Advanced Protection Current Limiting High Inrush Low Voltage Time Delay, Series: FNQ-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 250 mA, 600 V, 200 kAIC Interrupt, Class: CC, 12 s at 200% Response, Ferrule End Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine Tube, 13/32 in Dia x 1-1/2 in L Body Size
MFG #: BK/FNQ-R-1/4

EECO #: BUBKFNQR1/4

Brand: Bussmann
UPC #: 051712269179
Attributes
Features
Documents
Product Information
Attributes
Class
CC
UNSPSC
39121607
Material
Melamine Tube
Application
Industrial Facilities and Factories, Safety and Security Systems, Branch Circuits, Line Protection, Small Control Transformers, Isolated and In-Line Fuse Holders Applications
Mounting Type
Holder
Response Time
12 s at 200%
Terminal Type
Ferrule End
Voltage Rating
600
Type
Advanced Protection Current Limiting High Inrush Low Voltage Time Delay
Series
FNQ-R
Amperage Rating
250
Features
  • Time delay compatible with inrush characteristic of small control transformers
  • Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
  • 200 kA interrupt rating provides high ratings at all circuit locations
  • Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
  • Fast acting fuse helps prevent equipment damage caused by short circuit events
  • Rejection type fuse fits both standard and rejection style holders
  • Ideal for critical industrial or commercial applications that have specific current limitation requirements
  • 200 kA at 600 VAC RMS symmetrical interrupt rating
  • Melamine tube, nickel plated brass end caps
BK_FNQ_R_1_4_Specification_Sheet
