Bussmann AGX-6 Small Dimension Fast Acting Fuse With Nickel Plated Brass End Caps, 6 A, 250 VAC, 200 A, 10 kA Interrupt, Cylindrical Body
Share Share Print Print
Eaton

Bussmann AGX-6 Small Dimension Fast Acting Fuse With Nickel Plated Brass End Caps, 6 A, 250 VAC, 200 A, 10 kA Interrupt, Cylindrical Body

Short Description

Ensure reliable protection for your electrical circuits with the Bussmann AGX-6 Small Dimension Fast Acting Fuse. Designed for efficiency, this 6 A fuse features durable nickel-plated brass end caps and a compact cylindrical body, making it ideal for various applications. Experience peace of mind with its impressive interrupt rating of 10 kA!Enhanced by AI

Bussmann Fast Acting Fuse, Small Dimension, Series: AGX, Non-Indicating, Rejection, 6 A, 250 VAC, 200 A, 10 kA Interrupt, 4 hr, 60 min, 5 s, 2 min Response, Ferrule Terminal, Holder Mounting, Cylindrical Body, Single Element, Glass, 1/4 in Dia x 1 in L Body

MFG #: AGX-6

EECO #: BUAGX6

Brand: Bussmann
UPC #: 051712704885
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121607
Material
Glass
Application
Instruments, Electronic and Small Appliance Circuits Applications
Mounting Type
Holder
Response Time
4 hr, 60 min, 5 s, 2 min
Terminal Type
Ferrule
Voltage Rating
250
Type
Small Dimension
Series
AGX
Amperage Rating
6
Features
  • Size rejects insertion of other fuse types
  • 4 hr minimum at 110%, 60 min maximum at 135%, 5 sec maximum at 200%, 2 min maximum at 200% response time
  • 200 A at 250 VAC, 10 kA at 125 VAC interrupt rating
Bussmann_AGX_1_Catalog
IDW_DOCUMENT_a7288632db4157a8f3d074cf5f563caac380008892efd8abbe72fd08f6634776
IDW_DOCUMENT_415a8fb1835e484a4095cc995e5275f18dbbecc143937ed16f029ce51b5f425c
IDW_DOCUMENT_c421d5776d8b6092328a216f380c943e4fbc2efafe1f76332681c739f0fa9dd2
Bussmann_AGX_1_200_Catalog
