Eaton

Edison AGC-V-5-R Small Dimension Fast Acting Fuse With Axial Leads, 5 A, 250 VAC, 200 A Interrupt

Short Description

Fast-acting, glass tube 1/4" x 1-1/4" ferrule fuse designed to UL 248-14 for overcurrent protection of electronic circuits. Install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation. Eaton's AGC fast-acting, glass tube 1/4" x 1-1/4" ferrule fuses are designed to UL 248-14 for overcurrent protection of electronic circuits. Order in cartridge fuse format and install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation.

Edison Fast Acting Fuse, Small Dimension, Series: AGC, Indicating/Non-Indicating: Non-Indicating, 5 A, 250 VAC, 200 A Interrupt, 60 min 135% Amp Rating/120 s 200% Amp Rating Response, Glass, 1/4 in Dia x 1-1/4 in L Body Size
MFG #: AGC-V-5-R

EECO #: BUAGCV5R

Brand: Edison
UPC #: 051712654715
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121609
Material
Glass
Application
For electronic circuits
Response Time
60 min 135% Amp Rating/120 s 200% Amp Rating
Voltage Rating
250
Type
Small Dimension
Series
AGC
Amperage Rating
5
Features
  • Original electronic glass tube fuse
  • Fast acting for maximum protection
  • Wide amp/volt ratings allow versatility of protecting electronic circuits
  • Glass tube, nickel plated brass end cap construction
Bussmann_AGC_V_5_R_Specification_Sheet
AGC_V_15_R_Specification_Sheet_01
