Edison 7.2WFMSJ100 Motor Fuse Link, 7.2 kV, 100 A

Short Description

Motor fuse links providing short circuit protection in motor circuits to both the motor starter and cables from the starter to the motor.

Edison Motor Fuse Link, 7.2 kV, 100 A, Rated Breaking Capacity: 63 kA, 76 mm Dia x 442 mm L
MFG #: 7.2WFMSJ100

EECO #: BU7.2WFMSJ100

Brand: Edison
UPC #: 051712794633
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121626
Application
For used with motor protection
Voltage Rating
7.2
Type
British Standard DIN Dimensioned Medium Voltage
Series
WFMSJ
Dimensions
76 mm Dia x 442 mm L
Amperage Rating
100
Features
  • Cool running, low watts loss and power dissipation thanks to the m-effect ensuring high levels of substation utilization
  • Silver elements ensuring high conductivity and low power (revenue) loss
  • 100% X-Ray, all our medium voltage fuse links are X-Rayed ensuring the highest possible standards are maintained
  • Allows motor start current to pass on without degradation of fuse link
