Bussmann 630NHG3BI-400 Dual Indicator Low Voltage Size 03 NH Fuse Link, 400 V, 630 A, For Use With Class C/gG/gL Fuse, Ceramic

Short Description

Eaton's Bussmann series low voltage NH fuses range from 2 amps to 1250 amps and provide world class leading performance and reliability. The range is fully compliant with IEC 60269-1, 60269-2, VDE 0636-2 third party approval and DIN 43620. Incorporating a dual indicator design (front and top) NH fuses are able to give both local visual indication and remote (via microswitch) fuse status. Eaton's Bussmann series NH fuses are available in the following operating classes gg, gff and am.

Bussmann NH Fuse Link, Dual Indicator Low Voltage Size 03, Series: NHG, 400 V, 630 A, 45 to 62 Hz, Rated Breaking Capacity: 120 kAIC, Holder Mount, For Use With: Class C/gG/gL Fuse, Ceramic, 88.583 in L x 59.843 in W x 35.827 in H
MFG #: 630NHG3BI-400

EECO #: BU630NHG3BI400

Brand: Bussmann
UPC #: 051712233552
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121627
Material
Ceramic
Application
Electrical Assemblies, Panels, EOEMs, Control Panels for Machines, Panel Builders, Industrial Facilities and Factories, Safety and Security Systems, Power Distribution and Control Applications
Mounting Type
Holder
Voltage Rating
400
Frequency Rating
45 to 62
Type
Dual Indicator Low Voltage Size 03
Series
NHG
Dimensions
88.583 in L x 59.843 in W x 35.827 in H
Amperage Rating
630
Suitable For Use With
Class C/gG/gL Fuse
Features
  • Model: Bussmann 630NHG3BI-400
  • Type: Dual Indicator Low Voltage Fuse Link
  • Size: 03
  • Voltage Rating: 400 V
  • Current Rating: 630 A
  • Frequency Range: 45 to 62 Hz
  • Rated Breaking Capacity: 120 kAIC
  • Holder Mount: Yes
  • Compatibility: For use with Class C/gG/gL fuses
  • Material: Ceramic
  • Dimensions: 88.583 in L x 59.843 in W x 35.827 in H

Enhanced by AI

125NHG00BI_400_Specification_Sheet_02
Bussmann_630NHG3BI_400_Specification_Sheet
