Eaton

Edison Bussmann 224NHG1B NH Fuse Link, 500 VAC, 224 A, For Use With Class C gG/gL Fuse, Ceramic

Short Description

Bussmann's range of 500 V NH square bodied industrial fuse links is suitable for a wide variety of applications.

Edison Bussmann NH Fuse Link, Series: NHG, 500 VAC, 224 A, 45 to 62 Hz Frequency, Rated Breaking Capacity: 120 kA, For Use With: Class C gG/gL Fuse, Ceramic, 39.65 mm D x 135 mm H Dimensions
MFG #: 224NHG1B

EECO #: BU224NHG1B

Brand: Edison
UPC #: 051712626040
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121626
Material
Ceramic
Application
Safety and Security Systems, Industrial Facilities and Factories Facility, Power Distribution and Control, Electrical Assemblies, Panels and EOEM, Aftermarket, Panel Builders and Control Panels for Machines Applications
Mounting Type
Holder
Voltage Rating
500
Frequency Rating
45 to 62
Type
Size 1 Dual Indicator Low Voltage
Series
NHG
Dimensions
39.65 mm D x 135 mm H
Amperage Rating
224
Suitable For Use With
Class C gG/gL Fuse
Features
  • Reliable dual indicator system
  • Low temperature rise
  • Compatible with Eaton's Bussmann® series NH fuse bases and NH fuse gear
  • 1 size NH fuse body
  • GG/gL class of operation
  • Live gripping lugs
