EATON Bussmann 15LHLE-150E LHLE 1-Barrel General Purpose Helix Current Limiting Fuse, 150 A, 14.4 kV, 63 kA Interrupt, Class: E

Short Description

EATON offers a wide range of interrupting ratings in single barrel designs with ratings extended to higher currents in double, triple and quad barrel designs. E-rated fuses are available in both long (CLE), intermediate (LHLE) and short (HLE) clip center designs.

EATON Bussmann Current Limiting Fuse, 1-Barrel General Purpose Helix, Series: LHLE, Indicating, 150 A, 14.4 kV, 63 kA Interrupt, Class: E, Bolt-On/Clip/Hook Eye Mounting, Pure Silver Element, Glass Resin Casing/Silica Sand Filler, 20.53 in L x 3 in W x 3 in H Body
MFG #: 15LHLE-150E

EECO #: BU15LHLE150E

Brand: Eaton
UPC #: 786685494999
Attributes
Features
Documents
Product Information
Attributes
Class
E
UNSPSC
39121628
Material
Glass Resin Casing/Silica Sand Filler
Application
Power, Transformers, Capacitor Banks, Fused Switches and Indoor/Outdoor Applications
Mounting Type
Bolt-On/Clip/Hook Eye
Voltage Rating
14.4
Type
1-Barrel General Purpose Helix
Series
LHLE
Amperage Rating
150
Features
  • Optimized energy exchange the double concentric helix configuration (inner and outer) optimizes energy exchange by making more efficient use of the sand filler
  • Improved arc control the double helix design has more elements for more surface area permitting better arc control
  • Lower temperature rise heat radiation with the HLE design is excellent resulting in lower normal operating temperatures
  • Promotes faster melting under overload conditions, thermal transfer from the inner helix is reduced by a modified temperature gradient leading to faster melting
  • Blown fuse indication blown fuse striker pin will protrude from the top of the fuse providing a visual indication of operation, as well as a triggering means for external devices
  • Interchangeability helix type fuses are mechanically interchangeable and in many cases have higher maximum current ratings than competing current limiting fuses
  • E-rated power
  • Intermediate clip center designs
  • Disconnect and non-disconnect mountings, live parts
