Eaton

EATON 14002-2A Power Terminal Block, 600 V, 115 A, 14 to 2 AWG Cu, 8 AWG Al Wire

Short Description

Bussmann provides the broadest offering of UL listed cable limiters, welder limiters, circuit limiters and accessories. With products rated for AC or DC applications to suit your specific application requirements.

EATON Power Terminal Block, 600 V, 115 A, 2 Terminals, 14 to 2 AWG Cu, 8 AWG Al Wire, 4.5 Nm Torque, 150 deg C, 1.3 in L x 1.55 in W x 1.6 in H Dimensions
MFG #: 14002-2A

EECO #: BU140022A

Brand: Eaton
UPC #: 051712605472
Attributes
Features
Documents
Product Information
Attributes
UNSPSC
39121629
Wire Size
14 to 2 AWG Cu, 8 AWG Al
Application
Electrical Assemblies, Panels and EOEMs
Mounting Type
Chassis/Panel
Torque Rating
4.5
Voltage Rating
600
Connection Type
Screw
Temperature Rating
150
Type
2-Pole
Series
14002
Dimensions
1.3 in L x 1.55 in W x 1.6 in H
Amperage Rating
115
Features
  • Voltage Rating: 600 V
  • Current Rating: 115 A
  • Terminal Count: 2 Terminals
  • Wire Compatibility: 14 to 2 AWG Copper (Cu), 8 AWG Aluminum (Al)
  • Torque Specification: 4.5 Nm
  • Maximum Operating Temperature: 150 °C
  • Dimensions: 1.3 in (L) x 1.55 in (W) x 1.6 in (H)

Enhanced by AI

14002_2A_Specification_Sheet
