Print0.5 HP, 2.5 A, 180 VDC, ABB CDP3326 SCR Drive Motor, 0.625" Shaft, 1750 RPM, TENV
Short Description
0.5 HP, 180 VDC, 2.5 A, 1750 RPM, 0.625" Shaft, TENV, F Insulation Class, Permanent Magnet, SCR Drive Motor
SCR Drive Motor; Type Permanent Magnet; Power Rating 0.5 HP; Voltage Rating 180 Volt DC; Current Rating 2.5 Amp; Reversible Yes; Insulation Class F; Size 14.94 Inch Length; Frame Size NEMA 56C; Enclosure TENV; Mounting C-Face with Base; Service Factor 1; Application Conveyors, Mixers, Packaging Machinery; Approval UL, CSA; RoHS Compliant; Motor Type 3336P; Pulley End Bearing Type Sealed; Shaft Diameter 0.625 Inch; Base Speed 1750 RPM; Constant Torque Speed Range 20:1; Material Steel (Frame); Temperature Rating 40 Deg C
MFG #:
CDP3326
EECO #: BACDP3326
Brand:
Baldor-Reliance
UPC #:
781568124437
| Qty | Unit price |
|---|---|
| Ea | |
| 1 | $505.89 |
|
Slqt |
|
| 1 | $505.89 |
|
Stpk |
|
| 1 | $505.89 |
|
Unit |
|
| 1 | $505.89 |
ABB
everwhere
0.5 HP, 2.5 A, 180 VDC, ABB CDP3326 SCR Drive Motor, 0.625" Shaft, 1750 RPM, TENV
