Appleton® NEER™ LR125DCGSST Type LR Multi-Hub Conduit Outlet Body, 1-1/4 in Hub, 35.1 cu-in Capacity, Die-Cast Copper-Free Aluminum, Epoxy Powder Coated
Share Share Print Print
Appleton

Appleton® NEER™ LR125DCGSST Type LR Multi-Hub Conduit Outlet Body, 1-1/4 in Hub, 35.1 cu-in Capacity, Die-Cast Copper-Free Aluminum, Epoxy Powder Coated

Short Description

NEER™ all-in-one multi-hub threaded and set screw conduit bodies are used to connect and change direction of conduit runs. These conduit bodies serve as pulling fittings and permit access to conductors for splicing and maintenance.

Appleton® NEER™ Conduit Outlet Body, Type LR Multi-Hub, 1-1/4 in Hub, 2 Hubs, 35.1 cu-in Capacity, NEMA FB-1 Enclosure, Threaded/Set Screw Connection, Die-Cast Copper-Free Aluminum, Epoxy Powder Coated, 7.87 in L x 3.5 in W x 2.97 in H Dimensions

MFG #: LR125DCGSST

EECO #: APLR125DCGSST

Brand: Appleton
UPC #: 687855001132
Attributes
Features
Documents
Product Information
Attributes
Finish
Epoxy Powder Coated
UNSPSC
39131708
Hub Size
1-1/4
Material
Die-Cast Copper-Free Aluminum
Application
For use to provide access to the interior of the raceway for wire pulling, splicing and maintenance, allows connection of straight and branch conduit runs, 90 deg bends and use with rigid, IMC and EMT conduit applications
Number of Hubs
2
Connection Type
Threaded/Set Screw
Enclosure
NEMA FB-1
Type
Type LR Multi-Hub
Capacity
35.1
Dimensions
7.87 in L x 3.5 in W x 2.97 in H
Features
  • Lightweight aluminum facilitates shipping, handling and installing
