Allen-Bradley IEC Term Blck 6.1x105x35.7mm Spr Clp
Share Share Print Print
Rockwell Automation

Allen-Bradley IEC Term Blck 6.1x105x35.7mm Spr Clp

Short Description

Enhance your industrial connections with the Allen-Bradley IEC Terminal Block, featuring a reliable spring clamp design for efficient conductivity and versatility in wire sizes. Enhanced by AI

Spring Clamp Terminal Block,One-Circuit Feed-Through Block,4 mm (# 22 AWG - # 10 AWG) or 2.5 mm (# 22 AWG - # 12 AWG),2 Connection points on each side,Gray (Standard),

MFG #: 1492-L4Q

EECO #: AB1492L4Q

Brand: Allen-Bradley
UPC #: 662073055242
Attributes
Features
Documents
Product Information
Attributes
Color
Gray (Standard)
UNSPSC
39121410
Base Block Type
One-Circuit Feed Through Block
Base Block Style
Standard Feed-Through Blocks
Special Features
2 Connection points on each side
Wire Range
UL: 26-10 AWG (33A @600V AC/DC) CSA: 26-10 AWG (35A @600V AC/DC) IEC: 4mm² (32A @800V AC/DC) EEx e II: 4mm²/20-10 AWG (28A @550V AC/DC)
Maximum Wire Size & Rating
UL: 30-12 AWG (25A @600V AC/DC) CSA: 26-12 AWG (27A @600V AC/DC) IEC: 2.5mm² (24A @800V AC/DC) EEx e II: 2.5mm²/20-12 AWG (21A @550V AC/DC)
Features
  • Type: Spring Clamp Terminal Block
  • Design: One-Circuit Feed-Through Block
  • Wire Gauge Compatibility: 4 mm (#22 AWG - #10 AWG) or 2.5 mm (#22 AWG - #12 AWG)
  • Connection Points: 2 connection points on each side
  • Color: Gray (Standard)
  • Dimensions: 6.1 x 105 x 35.7 mm

Enhanced by AI

1492_td015__en_p
11994_O7FD2TCKUL0WE469
Qty Unit price
Ea
1 $2.82

Slqt
1 $2.82

Stpk
1 $141.00

Unit
1 $2.82
